Q235 Steel Structure Workshop Prefab Metal Warehouse SGS Certificate
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | XGZ |
| Certification: | CE ISO SGS |
| Model Number: | CHERRY-011302 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500sqm |
|---|---|
| Price: | USD 29.9-49.9 SQM |
| Packaging Details: | as per |
| Delivery Time: | 45 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 ton per year |
|
Detail Information |
|||
| Steel Building Wall/Roof Panel: | Single Color Sheet, Sanwich Panel | Carbon Structural Steel: | Q235 |
|---|---|---|---|
| Wall Purlin: | C Type Purlin | Design Load: | Wind, Snow, Earthquake |
| Main Frame: | Welded Or Hot-Rolled H Steel | Specification: | Steel Structure |
| HS Code: | 940600009 | Transport Package: | Steel Pallet And Container Shipping |
| Highlight: | Q235 Steel Structure Workshop,Prefab Metal Warehouse SGS,Q235 Prefab Metal Warehouse |
||
Product Description
Factory Customized Prefabricated Building Engineered Steel Structure Workshop
Steel structure building is a new type of building structure system ,which is formed by the main steel framework linking up H section,Z section and U section steel components,roof and walls using a variety of panels and other components such as windows, doors,cranes,etc.
It can be widely used for warehouse, workshop, garage,garden storage shed, airpaort,office building,apartment,and all kinds of steel buildings, metal buildings, modular house, steel frame for other riveting and welding parts. etc.
The sizes can be customized according to requirement.
Steel structure warehouse have the following advantages:
| Main Materials for steel structure warehouse | ||
| Item | Materials | Remark |
Steel Frame |
H section column and beam | Q355 steel, paint or galvanization |
| wind resistant column | Q355 steel,paint or galvanization | |
Secondary bracing |
Roof purlin | Q235B C/Z section galvanized steel |
| Wall purlin | Q235B C/Z section galvanized steel | |
| Tie bar | Q235,φ89*3.0 round steel pipe | |
| knee brace | angle steel,Q235,L50*4 | |
| roof horizontal bracing | φ20,Q235B steel bar, paint or galvanized | |
| column vertical bracing | φ20,Q235B steel bar, paint or galvanized | |
| casing pipe | φ32*2.5,Q235 steel pipe | |
| Pulling bar | Φ12 round bar Q235 | |
Roof and wall protecting system |
Wall and roof panel | corrugated steel sheet/sandwich panel |
| gutter | color steel sheet/galvanized steel/stainless steel | |
| Trim and flashing | color steel sheet | |
| downspout | PUC | |
| self tapping screw | M5.5*35 | |
Fastener system |
Anchor bolts | Q235 steel |
| High strength bolt | The Specifications shall be determined according to the design of steel structure. | |
| Normal bolt | ||
| Nuts | ||
| Window and door | Window | Aluminium windows |
| Door | According to requirement to choose,can be EPS door,windproof door,high-speed roll-up door,industrial sliding door etc | |
We purchase the best quality raw material for fabrication,and provide you with picture information of all production links, from raw materials to steel processing, the whole process of visual production,with strict quality inspection.
Full and advanced equipment:CNC laser cutting machine, vertical machining centers, CNC bending machines, NC drilling machine, CNC Continuous mode of production lines etc
Installation instruction and video will be provide, we can also send our engineers to your site as installation guide, they will teach your people how to build project.
Please kindly inform us informations as below if you are interested in our products ,then we design it.
1. Usage: for warehouse,workshop, showroom etc.
2. location: In which country will be built?
3. Local climate: Wind speed,Snow load (max. Wind speed)
4. Dimension: Length*width*height
5. Crane beam: Are there cranes inside the steel structure?
