Lightweight Prefab Metal Steel Warehouse Building With High Seismic Resistance
Product Details:
| Place of Origin: | China Qingdao |
| Brand Name: | XGZ |
| Certification: | CE, ISO |
| Model Number: | XGZ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 square meter |
|---|---|
| Price: | US $25-100 square meter |
| Packaging Details: | Standard Container |
| Delivery Time: | 30 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Ton Per Month |
|
Detail Information |
|||
| Usage: | Warehouse/Workshop | Material: | Steel Column, Steel Beam |
|---|---|---|---|
| Size: | Customizable | Door Type: | Rolling Door |
| Window Type: | Aluminum Alloy Sliding Window | Wall Type: | Steel Sandwich Panel |
| Installation Time: | Less Than 30 Days | Insulation: | Glass Wool |
| Highlight: | Lightweight Prefabricated Metal Warehouse,High Seismic Resistance Prefabricated Metal Warehouse,Lightweight Prefabricated Warehouse Building |
||
Product Description
Lightweight Prefab Metal Steel Warehouse Building With High Seismic Resistance
Product Description
Steel structure workshop is the third generation construction. It adopts H type beam, C type purlin or Z type purlin to combine or build framework. Roof and wall are single panel or Eps/ Glasswool/ rockwool/ PU sandwich panel. Steel structure supermarket has basically substituted traditional reinforced concrete in developed country. It has many excellent characteristics like light weight, big span, fewer materials, low cost, short building cycle, beautiful appearance, etc. It is widely applied to workshop, storage, warehouse, shed, garage, business architecture, office block, multistorey parking space, and family house, etc.
Features
1. Attractive design: the whole Steel structure workshop looks beautiful and elegant. The inner/ outer walls and the roof boarding all use the color steel panel, the filling material could be thermal core.
2. Light weight and convenient in shipping.
3. Easy to assemble and dismantle: the steel structure workshop can be rebuilt for dozens of times. The assembling only requires simple tools: plugs and screw, and we can sent engineers to help you to install.
4. Firm structure: the steel structure warehouse adopts steel frame structure and sandwich panels.
5. Waterproof: Our warehouses are completely waterproof.
6. Customized. The roof, wall, door, windows can be chosen by the customer.
7. Durable: the steel frame parts are all processed with anti-corrosion coating and can be used for as long as 50 years from the design.
Coating
1. Painting:Alcohol acid paint, epoxy zinc rich paint and chlorinated rubber paint. Various colors available.
2. Hot dip galvanize: The hot dip galvanizing thickness is about 60~120 microns and 275~500g/per square meters
Welcome to use our Steel structure supermarket!
| Length | Single slope, double slope, muti slope |
| Width | Single span, double-span, Multi-span |
| Height | single floor, double floors |
| Column | Q235, Q345 welded H section steel |
| Beam | Q235, Q345 welded H section steel |
| Purlin | Q235 C channel or Z channel |
| Knee brace | Q235 angle steel |
| Vertical and transversal support | Q235 angle steel, round bar or steel pipe |
| Tie bar | Q235 steel pipe |
| Brace | Q235 round bar |
| Cladding system | EPS, PU, Fiberglass rockwool sandwich panels or corrugated steel sheet with fiber glass wool insulation. available in Diferent colors&gauge |
| Partition wall | sandwich panels (EPS, PU, Fiber glass wool etc.) available in Diferent colors&gauges |
| Door | sandwich panel sliding door or roller door |
| Gutter | stainless steel or color steel sheet |
| Rainspout: | PVC |
| Live load on roof | In 120kg/Sqm (Color steel panel surrounded) |
| Wind resistance grade | 12 grades |
| Earthquake-resistance | 8 - 9 grades |
| Structure usage | Up to 50 years |
| Finishing options | vast array of colors and textures available |
| Paint Options | Gray paint, red paint, white paint, expoxy zinc etc. Or Galvanized |
Packing and Shipping
Advantages of pallet: high efficiency, in the case of pallet, loading or unloading only need 7 minutes to fill the container.
| Item | Way of loading |
| Steel column and beam | Pallet or In bulk |
| Purlin | In bulk |
| Brace | Pallet (With steel column/beam) |
| Roof and wall | Pallet or In bulk |
| Door | In bulk |
| Window | In bulk |
| Crane | Pallet or In bulk |
| Bolts and tapping nails | With the wooden box |
Thank you for browsing. If you are interested and would like more information, please contact me.
